On December 5, 2024, the 8th International Carbon Materials Conference opened in Shanghai. As a pioneer in diamond materials, High Light Intelligence Technology made a brand new appearance and achieved fruitful results on the first day.

At the exhibition, we will fully display our latest research and development results and products, including industrial diamond products, jewelry lab-grown diamond products, etc., so that you can experience our technical strength and product advantages in person. In particular, our major breakthrough in the field of MPCVD equipment —— the newly upgraded 10kw 90mm diameter deposition area MPCVD equipment and the latest 15kw 100mm deposition area MPCVD equipment.




High Light Intelligence Technology, a pioneer in the CVD diamond industry, has advanced MPCVD technology and CVD diamond production workshops. We focus on producing high-purity lab-grown diamonds for the jewelry industry, and at the same time create industrial-grade CVD diamond products, covering single crystals, polycrystalline, films and diamond surface metallization. We also provide 6kw/10kw/15kw MPCVD equipment to help customers in all aspects, from equipment to products, and then to all-round services, to create brilliance together.

On the first day of the exhibition, High Light's W1010 booth attracted many professional visitors and experts. The team enthusiastically displayed the latest research and development results of diamond materials, and high-purity diamonds and industrial CVD diamond products were praised. The company's technical experts shared their research results at the forum to promote the development of the industry. High Light Intelligence also negotiated with many buyers and partners to lay the foundation for cooperation. The gains on the first day were not limited to the site, but also to deepen industry exchanges and cooperation and clarify the company's future development direction.
